Taking Signage to New Heights
BrightSign XT5 is built to elevate and future-proof your signage experiences with the perfect blend of power, performance, and versatility.

Dynamic Dashboards
Learn More

Live TV Integrations
Learn More

Realistic Visual Experiences
Learn More
Get to Know BrightSign XT5
Elevate your signage to new heights.

The XT5 Lineup
BrightSign XT5 is built to elevate and future-proof your signage experiences with the perfect blend of power, performance, and versatility. Industry-best video capabilities, immersive motion graphics and seamless live TV capabilities are the tools XT5 offers to create captivating displays for both single and dual screen experiences now and for years to come.
XT5 DatasheetXT5 Software


XT245
XT1145
XT2145
I/O Package
Standard
Expanded
Multiplex
HTML5 Performance Level
3D WebGL & real time data visualization
3D motion graphics, video and live TV
Dual HTML presentations driving 2 screens
HDR10 Video Decoding
Single 8K60p
Dual 4K60p (10-bit)
Full HD
Dual 4K60p (10-bit)
Full HD
Single 8K60p
Dual 4K60p (10-bit)
Full HD
Dual 4K60p (10-bit)
Full HD
Single 8K60p
Dual 4K60p (10-bit)
Full HD
Dual 4K60p (10-bit)
Full HD
Video Rotation
4K & Full HD
4K & Full HD
4K & Full HD
Image & Graphics Decoding
4K & Full HD
4K & Full HD
4K & Full HD
HDMI Outputs
1x HDMI 2.1a
1x HDMI 2.1a
1x HDMI 2.1a
1x HDMI 2.0a
1x HDMI 2.0a
HDMI In*
HDMI 2.0a
HDMI 2.0a
USB
1x USB-A
1x USB-C
1x USB-C
1x USB-A
1x USB-C
1x USB-C
Serial
3.5mm RS-232
3.5mm RS-232
GPIO
12-pin Phoenix Connector with 8 bi-directional Ports
12-pin Phoenix Connector with 8 bi-directional Ports
12-pin Phoenix Connector with 8 bi-directional Ports
IR
3.5mm In / Out
3.5mm In / Out
3.5mm In / Out
Ethernet
Gigabit with PoE+
Gigabit with PoE+
Gigabit with PoE+
Optional BrightSign Mobile USB Modem
X
X
Optional 256GB SSD Storage
X
X
X
Dimensions (WxDxH)
238.62 x 185.9 x 19.19 mm
238.62 x 185.9 x 19.19 mm
238.62 x 185.9 x 19.19 mm
Warranty, parts and labor
1 year (2 year in EU/UK)
1 year (2 year in EU/UK)
1 year (2 year in EU/UK)
*HDCP support coming soon in a future BrightSignOS update
